QL601: Precision Green Screen & Seamless CDN Streaming

As demand for video processing and live streaming continues to rise, developers need platforms that combine high performance with customizable media pipelines.

Through cross-compilation and GStreamer plugin development, green-screen removal on QL601 with Vulkan shaders enables real-time 1080p60/4Kp30 streaming to CDN platforms such as Twitch and YouTube — all built on the same development flow established for QL601.

The following sections detail the complete workflow, from environment setup and plugin development to real-time streaming deployment.

1. Development environment and version alignment

Set up a matching GStreamer version on WSL

Since QL601 adopts the Qualcomm SDK and ships with GStreamer by default, we need to set up on WSL (Windows Subsystem for Linux) a GStreamer version and plugin combination that matches or is newer than the one on QL601 for development and testing.

For GStreamer plugin development, refer to the official documentation: GStreamer and GStreamer Vulkan.

To develop Vulkan plugins for GStreamer, it is recommended to install the gst-plugins-bad package. This package includes plugins such as vkimageidentity, which serve as good starter examples. Depending on project needs, OpenGL can also be used for image processing; however, this article focuses on Vulkan + GBM (Generic Buffer Management) on the QL601 platform to achieve real-time image processing with optimal performance.

Prepare the following components on WSL (aligned with QL601 versions):
- GStreamer Core and Base/Good/Bad packages (with Vulkan support enabled)
- Vulkan SDK - glslangValidator / SPIR-V Tools (GLSL → SPIR-V compilation)

2. Getting started with `vkimageidentity`

Reference source location: ext/vulkan (gst-plugins-bad)
Developers new to GStreamer Vulkan plugin development can start with vkimageidentity. It is the simplest sample plugin and simply outputs the input image directly.

How to test (can be run directly in the WSL environment):

gst-launch-1.0 videotestsrc ! vulkanupload ! vkimageidentity ! vulkansink

If you can see the test pattern, the environment is installed correctly and the Vulkan plugins are functioning properly.

Shader test

The vertex shader used by vkimageidentity (such as identity.vert) can be modified for verification:

#version 450 core
layout(location = 0) in vec4 inPos;
layout(location = 1) in vec2 inTexCoord;
layout(location = 0) out vec2 outTexCoord;

void main() {
   gl_Position = inPos;
   outTexCoord = inTexCoord;
}

Recompile after making changes. If the output image shows the expected differences, you can confirm that the shader compilation and pipeline are working properly.

3. GBM and Vulkan integration

GBM (Generic Buffer Management) is a Linux buffer interface. With dma-buf, components can share GPU-usable image buffers, reducing latency and copies.

Why use `GBM`?

Zero-copy sharing: Export/import via dma-buf, allowing V4L2, GStreamer, display composition, and Vulkan to share the same memory, reducing CPU involvement and latency.
Data stays on the GPU: Avoid unnecessary CPU memory copies, resulting in lower latency and higher throughput.

Relationship with GStreamer

Use video/x-raw(memory:GBM) caps to express GBM memory; upstream and downstream must negotiate and agree on the memory type and pixel format (such as NV12, BGRA).

Relationship with Vulkan

Import GBM/dma-buf into Vulkan via VK_EXT_external_memory_dma_buf, processing directly on the GPU to form a zero-copy pipeline.

Value for QL601

Most QL601/Qualcomm plugins (such as qtivcomposer, qtivtransform) use GBM. If your plugin supports GBM, it can work with the whole hardware-accelerated chain.

Minimal viable validation

Common caps (examples):

video/x-raw(memory:GBM),format=NV12,width=1920,height=1080,framerate=60/1
video/x-raw(memory:GBM),format=BGRA,width=1920,height=1080

Display path minimal validation:

gst-launch-1.0 videotestsrc ! \
  "video/x-raw,format=NV12,width=1920,height=1080" ! \
  vulkanupload ! vkimageidentity ! vulkansink

Verify the GBM negotiation chain:

gst-launch-1.0 v4l2src device=/dev/video4 ! \
  "video/x-raw,format=NV12,width=1920,height=1080,framerate=60/1" ! \
  qtivtransform ! "video/x-raw(memory:GBM),format=BGRA" ! \
  vkimageidentity ! fakesink

Minimal GBM negotiation example

flowchart LR
    SRC["v4l2src /dev/video4"] --> CAPS1["video/x-raw,<br>NV12 1920x1080 60fps"]
    CAPS1 --> QT["qtivtransform"]
    QT --> CAPS2["video/x-raw(memory:GBM),<br>BGRA"]

flowchart LR
    subgraph CONTINUE
      CAPS2["video/x-raw(memory:GBM),<br>BGRA"]
    end
    CAPS2 --> VKID["vkimageidentity"]
    VKID --> SINK["fakesink"]

4. Develop a custom green-screen removal plugin (avtColorKeyProcessor)

On this basis, we developed a custom green-screen removal plugin:

1. Features

Vulkan acceleration: All processing runs on the GPU for best performance.
Precise green-screen removal: Our own algorithm improves common chroma key issues.
Controls: Settings like background-remove-level, edge-smooth-level for fine control.
Background replacement: Load a new background image and composite.
GBM integration: Works with GBM buffers used by the Qualcomm SDK to avoid conversions.

2. Chroma key basics

Chroma keying removes a specific color (usually green or blue) and then combines the subject with another background. It is widely used in:

Live streaming and virtual backgrounds: e.g., presenters placed into dynamic scenes.
Film/TV post-production: Background replacement and effects.
Online education and conferencing: Speakers can appear in front of teaching materials.
AR/VR applications: Integrate real people into virtual scenes.

3. Common challenges

Aliased edges and hair handling: Fine regions are prone to residuals or missing parts.
Color spill: Green or blue tinting around edges reduces naturalness.
Uneven lighting: Uneven on-site lighting causes inconsistent results.

4. Our improvements

We developed our own green-screen removal algorithm, and:
- Fully GPU-accelerated to ensure real-time processing performance.
- Detail preservation: Enhanced edge and hair handling for more natural subject-background blending.
- Natural color restoration, minimizing spill.
- Reference original background: Refer to the original green background before the subject enters to maintain more consistent removal.
- Integrated on the QL601 platform for seamless interoperation with Qualcomm native GStreamer plugins, suitable for professional streaming and imaging scenarios.

5. `avtColorKeyProcessor` design highlights

Render directly to GBM buffers via Vulkan (import external memory with VK_EXT_external_memory_dma_buf) to reduce data movement.
Real-time compositing: Combine the keyed foreground with a new background.
Adjustable settings: e.g., shadow-strength, edge-smooth-level, hue-shift for scene-specific adjustments.

5.1 Extend `vkimageidentity` with a custom fragment shader and GBM integration (processing flow)

Base copy and naming
Copy gst-plugins-bad/ext/vulkan/vkimageidentity into a new plugin (e.g., avtcolorkeyprocessor).
Write a custom fragment shader
Add colorkey.frag to implement background removal, edge smoothing, and foreground/background compositing as needed.

Example:

#version 450 core
layout(location = 0) in vec2 inTexCoord;
layout(set = 0, binding = 1) uniform sampler2D inTexture;
layout(location = 0) out vec4 outColor;
void main() {
  vec4 color = texture(inTexture, inTexCoord);

  // Implement image processing algorithm (omitted)

  outColor = color;
}

Pads and GBM negotiation
Sink/Source pad templates declare support for video/x-raw(memory:GBM) with explicit format (recommend BGRA for both input and output to facilitate shader sampling).

If the actual source is NV12, use qtivtransform upstream to convert to BGRA with memory:GBM:

... ! qtivtransform ! "video/x-raw(memory:GBM),format=BGRA" ! avtColorKeyProcessor ! ...

Import GBM dma-buf into Vulkan
Obtain the dma-buf fd corresponding to GBM from the GstBuffer. Enable VK_KHR_external_memory/VK_KHR_external_memory_fd to create the input VkImage via external memory import, and then create the corresponding VkImageView as the shader sampling source.
Prepare GBM output
Use the downstream-provided allocator or create a GBM Buffer Object to generate the output buffer, export a dma-buf, and create the corresponding output VkImage as the render target. After rendering, wrap this Buffer Object back into a GstBuffer (caps remain video/x-raw(memory:GBM),format=BGRA) and push downstream (e.g., qtivcomposer, v4l2h264enc).

Minimal validation pipeline

gst-launch-1.0 -e \
  v4l2src device=/dev/video4 ! \
    "video/x-raw,format=NV12,width=1920,height=1080,framerate=60/1" ! \
    qtivtransform ! "video/x-raw(memory:GBM),format=BGRA" ! \
    avtColorKeyProcessor ! \
    fakesink

6. Practical test results

With a Vulkan + GBM shader architecture, CPU usage is significantly reduced, and image latency stays in the millisecond range.
When connected with qtivcomposer, it can stably maintain 1080p60/4Kp30 output.

5. Shader compilation and cross-compilation workflow

1. Shader compilation flow

In Vulkan plugin development, shaders need to go through the conversion process GLSL → SPIR-V → C header:

Compile GLSL (.vert / .frag) into SPIR-V (.spv).
Convert into C arrays and embed inside the plugin.
Load directly at plugin startup and use to build the Vulkan pipeline.

This design avoids the plugin reading external files at runtime, improving stability and portability.

Common tools and sample commands (executed on the WSL dev machine):

# Compile GLSL to SPIR-V
glslangValidator -V -o identity.vert.spv identity.vert
glslangValidator -V -o identity.frag.spv identity.frag

# Convert to embeddable C arrays
xxd -i identity.vert.spv > identity_vert_spv.h
xxd -i identity.frag.spv > identity_frag_spv.h

2. Cross-compilation flow

Key points:

Clean builds: Clear old caches to keep results consistent.
Toolchain: Use the QL601 cross-compilation toolchain.
Automation: Set up automated builds to deploy quickly.

This process ensures that after testing in the WSL environment, the plugin can be quickly compiled and deployed to the QL601 platform.

Using the cross-compilation toolchain:

cmake -DCMAKE_TOOLCHAIN_FILE=../QL601_aarch64_toolchain.cmake ..
make -j$(nproc)

Deployment notes:
- Copy the compiled .so to /usr/lib/gstreamer-1.0/ on QL601.
- If placed in a non-default path, set GST_PLUGIN_PATH to point to the plugin directory.

6. Integration with Qualcomm GStreamer plugins

Most plugins provided by the QL601 SDK are based on GBM memory, for example:

qtivcomposer: multi-stream composition
qtivtransform: hardware-accelerated image conversion
v4l2h264enc: hardware H.264 encoding

So the custom Vulkan plugin must also output GBM format to work with Qualcomm plugins and avoid CPU copies and performance loss.

Example pipeline

Single-source processing + display:

gst-launch-1.0 -e \
  v4l2src device=/dev/video4 ! \
    "video/x-raw,format=NV12,width=1920,height=1080,framerate=60/1" ! \
    qtivtransform ! "video/x-raw(memory:GBM),format=BGRA" ! \
    avtColorKeyProcessor \
      use_new_background=true \
      background_image="/home/root/newbackground.jpg" ! \
    qtivtransform ! waylandsink sync=false fullscreen=true

flowchart LR
    SRC["v4l2src /dev/video4"]
    SRC --> CAPS1["video/x-raw,<br>NV12 1920x1080 60fps"]
    CAPS1 --> QT1["qtivtransform"]
    QT1 --> CAPS2["video/x-raw(memory:GBM),<br>BGRA"]

flowchart LR
    subgraph CONTINUE
      CAPS2["video/x-raw(memory:GBM),<br>BGRA"]
    end
    CAPS2 --> CK["avtColorKeyProcessor"]
    CK --> QT2["qtivtransform"]
    QT2 --> SINK["waylandsink"]

7. Build a real-time streaming pipeline (two video inputs; one with green-screen removal; PIP composited output)

The following example demonstrates a complete real-time keying and streaming pipeline:

gst-launch-1.0 -e \
  qtivcomposer name=mixer \
    sink_0::position="<0,0>" sink_0::dimensions="<1920,1080>" \
    sink_1::position="<500,0>" sink_1::dimensions="<608,1080>" sink_1::rotate=2 \
  \
  mixer. ! "video/x-raw(memory:GBM),format=NV12,width=1920,height=1080,framerate=60/1" ! \
  tee name=mtee \
    mtee. ! queue ! waylandsink sync=false fullscreen=true \
    mtee. ! qtivtransform ! queue ! \
      v4l2h264enc \
        extra-controls="controls,video_bitrate=6000000,video_gop_size=60" ! \
      h264parse config-interval=1 ! tee name=video_tee \
        video_tee. ! queue ! flvmux name=mux_twitch streamable=true ! \
          rtmp2sink location=rtmp://ingest.global-contribute.live-video.net/app/<twitch_key> \
        video_tee. ! queue ! flvmux name=mux_youtube streamable=true ! \
          rtmp2sink location=rtmp://a.rtmp.youtube.com/live2/<youtube_key> \
  \
  v4l2src device=/dev/video2 ! \
    "video/x-raw,format=NV12,width=1920,height=1080,framerate=60/1" ! \
    qtivtransform ! mixer. \
  \
  v4l2src device=/dev/video4 ! \
    "video/x-raw,format=NV12,width=1920,height=1080,framerate=60/1" ! \
    qtivtransform ! "video/x-raw(memory:GBM),format=BGRA" ! \
    avtColorKeyProcessor \
      use_new_background=true \
      background_image="/home/root/newbackground.jpg" ! \
    mixer.

Pipeline visualization

flowchart TD
    CAM1[v4l2src /dev/video2] --> QT1[qtivtransform] --> MIXER[qtivcomposer]
    CAM2[v4l2src /dev/video4] --> QT2[qtivtransform] --> VULKAN[avtColorKeyProcessor] --> MIXER
    MIXER --> TEE1[tee]
    TEE1 --> PREVIEW[waylandsink]
    TEE1 --> TRANS[qtivtransform] --> ENC[v4l2h264enc] --> PARSE[h264parse] --> TEE2[tee]
    TEE2 --> TW[flvmux mux_twitch] --> TWOUT[rtmp2sink Twitch]
    TEE2 --> YT[flvmux mux_youtube] --> YTOUT[rtmp2sink YouTube]

8. Conclusion

This article shows how to do the following on QL601:

Set up a GStreamer development environment
Use vkimageidentity to test Vulkan shaders
Understand GBM and Vulkan integration
Develop a custom plugin (avtColorKeyProcessor)
Compile shaders and cross-compile/deploy to QL601
Integrate with Qualcomm SDK GBM plugins
Build a real-time green-screen and multi-platform streaming pipeline

With QL601’s hardware acceleration and the flexibility of Vulkan shaders, developers can rapidly build a high-performance green-screen removal and real-time CDN streaming solution. This can be applied to live streaming and virtual conferencing, and further extended to AR/VR, remote education, and interactive entertainment.

Extended applications

The same approach also applies to GPU denoising, color grading, localized effects, and can integrate with AI models to build a complete intelligent audio/video processing platform on QL601.
